The RCYK overband magnet is similar like the most of other overband magnet.But it has the Armored belt,can provent the damage form sharp objects.
This RCYK overband magnet/permanent Magnetic Separator is specially designed for removing the iron impurities from all kinds of Specialized practical for steel slag iron separation, direct reduction iron works iron separation, slag iron,separationbraised workshop,
casting workshop selected iron iron selected various metallurgical slag. Armoured belt with special design, can effectively prevent the
damage of sharp ferromagnetic debris piled belt, economic operation. Magnetic field design and unique structure design, can effectively reduce the large iron reactor belt impact, prolong the service life.
Industries:
cement,thermal power plant, metallurgy ,mining,chemical ,paper making and coal industry .etc
Especially be used for eliminating the iron impurities from some specia applications,such as steel slag.
Design:
The RCYK overband magnet like the RCYDII overband magnet,its motor mounted upper for the application of narrow horizontal space but surplus upper space.The main function area is under the magnet block,and the magnet is covered by the automatic running discharge belt.When the tramp iron go though the function area,it will be captured by the magnet,and brought out by the running belt to the garbage area.
Note:we also provide the overband magnets customized service such as the size and the magnetic intensity.
►1. Permanent magnet and pakage structure reduce the noisy and breakdown,
►2. Neodymium magnet provide excllent performance,
►3. Low costs of maintanence and operation,
►4. Special sturcture for easy installation and disassemble.
You may also interested in below magnetic equipment or magnetic machine:
1. Magnetic separator/magnetic separators;
A: dry magnetic separator,wet magnetic separator,
B: low intensity magnetic separator,mid intensity magnetic separator,high intensity magnetic separator
C: high gradient magnetic separator,slon high gradient magnetic separator,
D: neodymium magnetic separator.
2. Overband manget/overband magnets,Magnetic Drums,Magnetic Pulleys;Magnetic Rollers
A: permanent suspended magent,permanet suspension magnet,permanent overband magnet,permanent cross belt magent.
B: electro magnet,electromagnetic separator,electro overband magent,electro crossblet magent.
C: permanent magentic drum,
D: permanent magnetic pulley
E: permanent magnetic rollers
3. Eddy current separators;
A: concentric eddy current separators
B: eccentric eddy current separators
4. Magnetic solutions EPC.
Right now,Tianli have developed more than thirty series of Tianli brand magnetic separators,Deferrization magnets,and mining equipments,etc.which include hundreds of products with different specifications.Tianli is good reputaion magnet supplier,magnetic separator supplier in china.If you are looking for the quality magnetic separator vendor,magnetic separator distributor,magnetic separatorfactory,or magnetic separator company. Tianli is your good choice.
